◆◆ Product Advantage
Zero-Emission Eco-Friendliness: Compliant Support for Green Warehousing
Adopts a dual lithium/lead-acid battery solution—the lithium version supports 1-hour fast charging and delivers an 8-hour full-charge runtime for all-day high-frequency operations. With zero exhaust emissions, it complies with EU EMEA and North American OSHA environmental regulations, making it ideal for clean-requirement warehouses (e.g., food, pharmaceuticals). Enterprises using it can reduce annual carbon emissions by ~1.2 tons, easily meeting carbon reduction goals.
(Keywords: Zero-Emission Electric Stacker, Eco-Friendly Warehouse Equipment)
High Efficiency: Boost Warehouse Turnover Rate
Equipped with a variable frequency drive (VFD) motor, it achieves a max lifting speed of 600mm/s and travel speed of 4km/h-30% faster than traditional fuel-powered stackers. Smooth start/stop with no jolts minimizes cargo sway and damage. Tested in a real e-commerce warehouse: order picking + handling time shortened by 25%, daily throughput increased to 1,200 cases, significantly improving operational efficiency.
(Keywords: High-Efficiency Electric Pallet Stacker, Warehouse Turnover Rate Improvement)
Intelligent Safety Protection: Reduce Accident Risks
Standard triple safety system: rear radar (1m detection range) for collision avoidance, anti-glare LED headlights to illuminate blind spots, and overload protection (automatic lifting lock at >105% load). Optional Bluetooth app monitoring provides real-time alerts on issues like low battery or motor abnormalities. Third-party testing shows a 40% reduction in collision accidents and increased operator confidence.
(Keywords: Intelligent Safety Electric Stacker, Electric Stacker Safety Configuration)
Low Maintenance Cost: Outstanding Long-Term Economy
The motor requires no lubrication or routine maintenance. The lithium version has a cycle life of over 2,000 cycles-twice that of lead-acid batteries. Annual maintenance costs are 40% lower than fuel-powered stackers: no need to replace engine oil or spark plugs, only regular battery and brake checks. Long-term use saves tens of thousands in operational expenses, ideal for budget-conscious businesses.
(Keywords: Low-Maintenance Electric Stacker, Electric Stacker Cost Advantage)
Flexible Adaptability: Covers All Scenario Needs
Compact body design with a turning radius of just 1.2 meters, easily maneuvering through narrow-aisle warehouses. Optional 100-1200mm wide forks and 3-6m lifting heights fit scenarios like e-commerce warehousing, manufacturing production lines, and cold chain logistics. For instance, cold storage can opt for low-temperature-resistant batteries (operating at -20℃) to meet special environment requirements.
(Keywords: Narrow-Aisle Electric Stacker, Customized Electric Stacker)
Core Keyword Density: Electric Stacker, Electric Pallet Stacker, Zero-Emission, Intelligent Safety, Low Maintenance, Narrow-Aisle
Data Trust Points: 1-hour fast charge/8-hour runtime, 25% efficiency improvement, 40% lower accident rate, 40% lower maintenance cost-using specific numbers to reinforce product value and help customers intuitively perceive its advantages.
◆◆ Technical Parameters
| Model Series | ES-A (General-purpose), ES-Z (Heavy-duty), ES-N (Narrow-aisle); Customizable (lift height/fork width/battery capacity) |
| Rated Load Capacity | 0.5-10 tons (standard); 12-15 tons (custom) |
| Standard Lifting Height | 3-6m (basic); extendable up to 10m (telescopic mast version) |
| Max Lifting Speed | 200-300mm/s (loaded, ES-A); 400-500mm/s (unloaded) |
| Travel Speed | 3-4km/h (loaded); 4-5km/h (unloaded) |
| Drive Motor | AC permanent magnet synchronous motor, 1.5-3kW (ES-A); 3-5kW (ES-Z) |
| Battery Type | Lithium (LiFePO4, 2000 cycles) / Lead-acid (maintenance-free, 800 cycles) |
| Battery Capacity | 24V/40Ah (0.5-2t); 48V/80Ah (3-10t) |
| Charging Time | Lithium: 1-1.5h (fast charge); Lead-acid: 8-10h |
| Runtime on Full Charge | Lithium: 8-10h (ES-A); Lead-acid: 6-8h |
| Safety Factor | ≥4:1 (static load); ≥2:1 (dynamic load) |
| Test Load | 1.25×rated load (no deformation after 10min) |
| Braking System | Electromagnetic brake (locks on power-off) + mechanical parking brake |
| Protection Rating | IP54 (dust/splash water); optional IP65 (chemical/coastal) |
| Overload Protection | Automatic lift lock at >105% load, with audible/visual alarm |
| Turning Radius | 1.2-1.5m (narrow-aisle ≤1.2m) |
| Mast Height (Min/Max) | 2.1m/3.8m (ES-A); 2.3m/6.2m (ES-Z) |
| Fork Specs | Width: 500-1200mm; Thickness: 80-150mm; Length: 1000-1500mm (customizable) |
| Net Weight | 450-1900kg (0.5-10t models) |
| Safety Certifications | CE (EU), ANSI B56.1 (USA), GB 20776 (China) |
| Operating Environment | Temp: -20℃ to +50℃; Humidity: ≤90%RH (no condensation); Altitude: ≤2000m |
◆◆ Product Uses
1. High-Frequency Handling in Warehouses
Applies to large e-commerce/third-party logistics (3PL) warehouses, handling short-distance transshipment and high-level stacking (3-6m) of palletized goods. Its zero-emission, low-noise design fits indoor use; lithium models offer 8-hour runtime, supporting over 1,000 daily moves and boosting warehouse throughput by 20%-30%.
2. Production Line Linkage in Manufacturing
Used in automotive/electronics factories to deliver raw materials (steel, coils) from storage to assembly lines. Compact size (≤1.2m turning radius) navigates equipment gaps; stable lifting (≤2mm error) prevents damage-ideal for clean workshops with no exhaust restrictions.
3. Emergency Response to E-Commerce Peak Seasons
During sales surges, its high efficiency (300mm/s lifting + 4km/h travel) rapidly completes picking-handling-shelving for bestsellers. Supports 1.5-hour fast charging and shift work, easing labor shortages and ensuring on-time delivery.
4. Low-Temperature Operations in Cold Chain Logistics
For -20℃ cold storage, opt for low-temp-resistant lithium batteries (maintains >80% runtime) and anti-condensation design to avoid circuit failures. Thicker forks (120mm) add freeze resistance, stabilizing frozen food/pharma transport.
5. Retail Backroom Replenishment
In small store backrooms (≤500㎡), narrow-aisle compatibility (min. 1.2m) allows deep shelf restocking. Simple operation (30-minute training) lowers staff barriers, fitting high-frequency, small-batch needs.
Each scenario leverages the stacker's core strengths-efficiency, safety, and adaptability-to solve real-world material handling pain points.
◆◆ Product Operate Guide
Pre-operation: Check battery level (≥20%), align forks with pallet slots, and wear anti-slip gloves. After startup, lower forks to the lowest position first, then slowly approach the goods. Adjust to fully insert forks into the pallet. During handling, maintain a steady speed (≤3km/h) and slow down when turning; lift vertically to target height for stacking, confirm stability before translating.
Post-use: Lower forks to ground, power off, and return to designated area. Keep sightlines clear at all times-stop immediately if anomalies occur.
◆◆ Product Video
◆◆ FAQ
Q: What should I do if the battery has insufficient endurance or cannot be charged?
A: First, check if the battery is fully depleted (charge when remaining capacity is ≥20%). Ensure the charger is properly connected. For long-term unused units, charge periodically to prevent sulfation. If issues persist, the battery may be aged or the charger faulty-replace the battery or repair the charger.
Q: What if the stacker fails to start or operates abnormally?
A: Check battery voltage (≥24V) and confirm the starter motor/controller are undamaged. If hydraulic pressure is abnormal (e.g., lifting failure), inspect the hydraulic pump, hoses, or seals for leaks.
Q: What if the forks lift slowly or fail to lift?
A: Possible causes include insufficient hydraulic oil, worn cylinder seals, or a clogged filter screen. Refill oil to the marked level, replace worn seals, and clean system debris.
Q: What if the stacker suddenly loses control or makes unusual noises during operation?
A: Immediately press the emergency stop to cut power. Check the braking system (pad thickness, brake fluid) and steering system (tie rods, ball joints). Noises may stem from unlubricated bearings or worn gears-lubricate or replace parts promptly.
Q: Which components require key attention in daily maintenance?
A: Daily: Check battery status, tire pressure, and hydraulic oil level. Monthly: Clean the radiator and lubricate chains. Quarterly: Test insulation resistance and controller parameters. Annually: Fully replace hydraulic oil and filters.
