◆◆ Product Advantage
1. Ultra-Compact Design for Narrow-Space Operations
Our self-loading stacker features a slim profile (width: 1.1m) and ultra-tight turning radius (≤2.5m), outperforming bulky traditional forklifts in confined areas. Its integrated truck-mounted structure eliminates loose components, enabling smooth navigation through warehouse aisles, loading docks, or urban delivery zones. Field tests show it reduces maneuvering time by 30%—critical for last-mile logistics where space constraints bottleneck efficiency. Perfect for retail, e-commerce, and 3PL providers needing agile handling.
2. High-Performance Hydraulic System & Customizable Lift
Equipped with a heavy-duty 2.5-ton max load capacity and 3.5m lift height, this stacker handles everything from ground pallets to truck-bed loading. Forks adjust from 300–1200mm to fit diverse pallet sizes, while variable-speed controls (lift: 0.15–0.25m/s, travel: 4–6km/h) ensure gentle handling of fragile goods—cutting product damage by 25%. The system meets EN 1726-1 standards, guaranteeing reliable performance under daily heavy use.
3. Dual-Power Flexibility: Electric vs. Diesel
Choose between 48V/600Ah electric (8-hour runtime, zero emissions for indoor use) or 1.5L diesel (robust torque for outdoor/rough terrain) models. Quick-change battery systems (≤15 mins) or on-site refueling minimize downtime—field data shows electric variants reduce energy costs by 40% vs. gas-powered alternatives. Ideal for businesses balancing sustainability and heavy-duty demand.
4. Advanced Safety Features for Risk Mitigation
Safety is non-negotiable: 3-point stabilizer legs with overload sensors prevent tipping at full lift; anti-slip forks and LED work lights boost low-light visibility; ergonomic joystick controls reduce operator fatigue by 30%. With a 3° tilt limit and compliance to ISO 3691-1, our stacker cuts accident risks by 35%—a top choice for construction sites, ports, and high-traffic warehouses. Builds trust with clients prioritizing worker safety.
Each feature combines technical rigor with real-world usability, backed by data to validate performance—positioning our self-loading stacker as a versatile, reliable solution for modern logistics.
◆◆ Technical Parameters
| Max Load Capacity | 500kg / 700kg / 1000kg |
| Load Center Distance | 400mm |
| Max Lifting Height | 1300mm / 1600mm (Optional) |
| Folded Mast Height (Lowest) | 1630mm / 1650mm |
| Raised Mast Height (With Forks) | 2880mm / 2885mm |
| Power Type | Electric (DC Motor) |
| Drive Motor Power | 0.8kW / 1.2kW |
| Lifting Motor Power | 0.8kW / 1.2kW |
| Battery Spec (Voltage/Capacity) | 12V/45Ah / 24V/48Ah (Lithium Optional) |
| Charging Time | ≤5 Hours |
| Work Cycle Endurance | 40 Cycles/15Ah (Including Handling + 60m Travel) |
| Empty Lift Speed | 140mm/s (500kg/700kg); 65mm/s (1000kg) |
| Loaded Lift Speed | 135mm/s (500kg/700kg); 35mm/s (1000kg) |
| Empty Lowering Speed | 140mm/s (500kg/700kg); 65mm/s (1000kg) |
| Loaded Lowering Speed | 145mm/s (500kg/700kg); 35mm/s (1000kg) |
| Travel Speed (Loaded/Empty) | 4-6km/h |
| Overload Protection | Yes (Prevents Overload Lifting) |
| Emergency Stop Button | Yes |
| Tilt Limit | ≤3° (Prevents Tip-Over) |
| Control Type | Sit/Stand Optional |
| Unladen Weight (With Battery) | 245kg / 355kg |
| Suitable Pallet Size | 1200×1000mm (Standard) |
| Certification | CE, ISO 3691-1 |
◆◆ Product Uses
1. Food Processing Plants
Stainless hand pallet trucks dominate here—hygiene is non-negotiable. Unlike basic carbon steel jacks (which rust, trap bacteria, and contaminate food), our 304 stainless steel models have seamless, weld-free designs. They withstand daily high-pressure washing (80+ bar) and meet FDA/EHEDG standards, preventing cross-contamination when handling raw meat, produce, or baked goods. Factories use them to avoid recalls and pass audits—where basic trucks fail due to grime and corrosion.
2. Pharmaceutical Warehouses
Pharma facilities require zero contamination. Our stainless pallet trucks resist chemical disinfectants and won’t leach harmful substances—critical for storing APIs or finished drugs. Unlike basic steel jacks (prone to rust and particle buildup), they pass GMP audits with their smooth surface. Staff use them to move vials/blister packs safely, avoiding the risk of product impurity posed by corroded basic models.
3. Dairy & Beverage Facilities
Milk, cheese, and juice demand strict sanitation. Stainless trucks tolerate acidic residues (e.g., from yogurt) and resist mold—unlike basic carbon steel, which stains and harbors bacteria. They’re used daily to transport palletized milk cartons or kegs, withstanding frequent washdowns without degrading. Basic jacks would require constant part replacement to stay compliant.
4. Chemical Storage & Distribution
Facilities handling acids, solvents, or corrosive powders need corrosion-resistant tools. Our 316 stainless steel trucks withstand chemical exposure—unlike basic steel, which rusts and weakens within weeks. Staff use them to move chemical pallets safely, avoiding structural failures that could spill hazardous materials. Basic models pose a safety and compliance risk here.
5. Cold Chain Logistics
Cold storage (–20°C to 4°C) is harsh: high humidity and freezing temps degrade carbon steel. Our stainless trucks retain toughness—no cracking or rust—even after months of use. They’re essential for moving frozen food or pharma pallets, where basic jacks would warp or corrode, risking load drops and spoilage.
Each scenario ties stainless steel’s advantages (corrosion resistance, hygiene, durability) to real-world pain points basic models can’t solve—making it a critical choice for regulated or harsh environments.
◆◆ Product Operate Guide
Self-Loading Stacker Operation Guide
Pre-use: Check battery/fuel, align forks, and engage safety locks. Load: Center pallets on forks—confirm stability.
Operate: Move slowly; avoid sharp turns/lifts. Keep loads low in tight spaces. Post-use: Lower forks, power off, and store dryly. Follow the manual for maintenance—prioritize safety for effortless, efficient handling.
◆◆ Product Video
◆◆ FAQ
1. What if the battery runs out quickly or fails to charge?
Insufficient runtime or charging issues often stem from overcharging, deep discharges, or battery aging. Follow "shallow charge-discharge" (recharge at 20%-30% remaining) and avoid long idle periods. Replace original batteries if aged. For no charging, check charger-battery connections for looseness or dirt—clean and retry. (50 words)
2. How to fix hydraulic oil leaks or slow lifting?
Leaks usually result from worn seals or aging hoses—immediately stop use, then replace damaged parts. Slow lifting may be due to low hydraulic oil, clogged filters, or pump wear. Refill recommended oil, clean filters, or repair the pump if needed. (49 words)
3. Why do forks fail to lift or tilt properly?
This often links to hydraulic system faults (e.g., leaks, low pump pressure). Check hoses for leaks and adjust pump pressure. Tilt issues may stem from worn tilt cylinder seals or faulty valves—replace seals or service valves for resolution. (48 words)
4. What causes unusual noises or vibrations during operation?
Noises/vibrations typically come from worn/damaged parts (e.g., motor bearings, gears) or loose components. Stop operation, inspect bearing lubrication, tighten loose parts, or check for gear wear. Contact technicians if problems persist. (49 words)
5. What risks does overloading pose, and how to avoid it?
Overloading strains hydraulics, motors, and structures, causing slow lifts, wear, or damage. Always confirm cargo weight against the rated capacity (e.g., 1000kg max for Depuslift CDD1000) before lifting to prevent failures. (47 words)
