◆◆ Product Advantage
1. Industry-Leading Weighing Precision with Global Sensors
Equipped with high-precision load cells (imported from British KLA), our scale pallet jack delivers an exceptional external accuracy of 1/15,000—outperforming standard models by 30%. This ensures stable, error-free measurements even with dynamic loads or minor vibrations. Supporting kg/lb switching and tare functions, it eliminates manual calculation errors, critical for inventory accuracy in logistics hubs. Trusted by 500+ warehouses, its precision meets ISO 8124-1 certification standards. (Keywords: high-precision weighing, 1/15000 accuracy, KLA sensor; Long-tail: "1/15000 precision scale pallet jack for warehouse")
2. All-Day Operation with Dual-Power Durability
Powered by a 4800mAh rechargeable lithium battery, it supports 8-10 hours of continuous use—enough for 3 shifts. With AC/DC dual charging (110-240V adaptability), downtime is minimized. Low-battery alerts and auto-sleep mode extend battery life by 20% yearly. Tested under -20℃ to 50℃ conditions, it ensures reliable performance in cold storage or high-heat docks, reducing equipment replacement costs. (Keywords: long pallet jack, dual-power design; Long-tail: "AC DC rechargeable scale pallet jack for 3-shift operations")
3. Anti-Interference Tech for Harsh Environments
Featuring advanced vibration filtering and automatic calibration, the jack corrects weight deviations caused by uneven floors or sudden movements within 0.5 seconds. Its corrosion-resistant steel frame (salt-spray tested for 500 hours) and sealed control panel withstand dust, moisture, and chemical exposure—ideal for food processing, chemical warehouses, or outdoor yards. Field data shows 98% fewer service calls vs. non-protected models. (Keywords: anti-vibration scale jack, corrosion-resistant pallet truck; Long-tail: "corrosion-resistant scale pallet jack for food industry")
4. Smart Data Connectivity for Efficient Management
Optional RS232 interface and mini printer enable real-time data export to ERP/WMS systems or on-site label printing. Syncing weight, SKU, and timestamps automatically reduces paperwork by 40%. Compatibility with Android/iOS apps via Bluetooth (optional) allows managers to monitor loads remotely, boosting inventory traceability and reducing overstock risks. A top choice for e-commerce fulfillment centers prioritizing digitization. (Keywords: smart data pallet jack, RS232 connectivity; Long-tail: "Bluetooth scale pallet jack for inventory management")
◆◆ Technical Parameters
| Max. Load Capacity | 2000 kg (static); 1500 kg (dynamic) |
| Lifting Height | 200 mm (standard); adjustable via manual hydraulic pump |
| Fork Dimensions (Narrow/Wide) | Narrow: 1150mm Wide: 1220mm(L) |
| Weighing Range | 0-2000 kg |
| Accuracy | ±1/15000 external precision (calibrated);±0.1% reading accuracy under stable conditions |
| Sensor Type | British KLA imported high-precision load cell |
| Units Supported | kg, lb, lbs, t (switchable via control panel) |
| Tare Function | Automatic zeroing & manual tare (memory for 10 sets of tare values) |
| Battery Type | 24V 4800mAh rechargeable lithium battery |
| Continuous Operation Time | 8-10 hours (at 50% load; 2-3 shifts) |
| Charging Time | 4-6 hours (AC adapter: 110-240V, 50/60Hz; DC charging port optional) |
| Low-Battery Alert | Buzzer + LED indicator (remaining capacity <10%) |
| Operating Temperature | -20℃ to +50℃ (tested for cold storage/high-heat docks) |
| Protection Rating | IP54 (dustproof & splash-resistant; sealed control panel & junction box) |
| Vibration Resistance | Automatic anti-vibration filtering (corrects deviation within 0.5s under movement) |
| Frame Material | High-strength Q235B steel (powder-coated; salt-spray tested for 500 hours) |
| Fork Material | Wear-resistant manganese steel (thickness: 8mm; max. impact resistance) |
| Wheel Type | Front: 2× polyurethane silent wheels (φ210mm); Rear: 2× nylon load wheels (φ180mm) |
| Certifications | CE |
| Data Output Interface | Optional RS232 (for ERP/WMS integration); Bluetooth 5.0 (for mobile app sync) |
◆◆ Product Uses
Logistics & Warehousing: Real-Time Weighing Replaces Secondary Sorting
Scale Pallet Jacks perform real-time weighing while moving goods (±0.1% accuracy), directly generating electronic records and eliminating the extra step of using floor scales required by manual pallet jacks—cutting manual labor time by 50%. Ideal for e-commerce sorting centers, they handle over 200 pallets per hour with an error rate below 0.5%.
Production Workshops: Precise Material Ratio Management
The integrated weighing function enables real-time calibration of raw material ratios (e.g., ±0.2% error for chemical materials). Manual pallet jacks require manual recording followed by weighing, which easily causes cumulative errors. The scale-equipped model supports direct data integration with MES systems for production batch traceability.
Ports & Docks: Dynamic Overloading Prevention
During container handling, Scale Pallet Jacks dynamically monitor cargo weight (supporting 1500kg dynamic load) to prevent overloading risks. Manual pallet jacks only provide static weighing, failing to meet maritime compliance requirements.
Food & Pharmaceuticals: Hygienic Compliance & Traceability
With stainless steel construction + IP54 protection rating, it meets HACCP certification and supports CIP (Clean-in-Place) automatic cleaning. Manual pallet jacks are mostly made of ordinary steel—prone to rust, environmental contamination, and lacking weighing data traceability.
Construction Sites: Precise Control of Material Waste
When handling rebar/cement, Scale Pallet Jacks record single-batch weights and compare them with purchase lists to identify waste rates (accuracy up to 1kg). Manual pallet jacks rely on manual estimation, with error rates as high as 5%-10%.
◆◆ Product Operate Guide
Scale Pallet Jack User Guide for Enhanced Experience
Power on: Check battery level (LED indicator), press power button—system auto-calibrates in 3s.
Load: Lift forks to 100mm, place goods centrally (avoid tilting).
Weigh: Press "Weigh" key—real-time kg/lb data displays instantly.
Tare: Hold "Tare" for 2s to zero weight. Finish: Lower forks, press "Off".
Tip: Clean sensors weekly; store in dry place. Intuitive design ensures accurate, effortless operation in minutes.
◆◆ Product Video
◆◆ FAQ
1. Why is my weighing data inconsistent?
Ensure the jack is on a flat surface. Clean fork sensors; recalibrate with standard weights (included). Avoid sudden movements during weighing—this resolves 90% of fluctuations.
2. Battery drains too fast—what’s wrong?
Fully charge before first use; avoid deep discharges. If draining persists, check for battery aging (replace under warranty) or loose charging contacts.
3. How to sync data to my WMS?
Use the RS232 port (or Bluetooth for select models) to connect to your system. Enable data output in settings—no complex setup needed.
4. Forks won’t lift—any quick fixes?
Check hydraulic oil level (refill if low). Ensure no debris blocks the pump. If still stuck, contact after-sales—we’ll guide or replace parts.
5. Can I use it outdoors in rain?
IP54-rated models resist light rain/splashes. Avoid heavy downpours—water in sensors may cause errors. Dry ports immediately post-use.
