◆◆ Product Advantage
Powerful Power and Long-lasting Battery Life for High-frequency Operations
Equipped with a 48V/240Ah large-capacity lithium battery, it can achieve a range of 120 kilometers on a single charge and supports fast charging to 90% in 1.5 hours. The 5kW permanent magnet synchronous motor provides strong driving force, reaching a speed of 6km/h when fully loaded. The daily handling frequency is 35% higher than traditional electric pallet trucks, easily meeting the demand of over 500 cargo transfers per day in logistics warehouses.
Keywords: lithium battery endurance, high-frequency operations, permanent magnet synchronous motor
Intelligent Safety System with Multiple Protections for Higher Reliability
Equipped with an intelligent load sensor, it automatically restricts operation and issues audio-visual alarms when overloaded. The emergency braking response time is ≤0.3 seconds, and with anti-skid tires (friction coefficient 0.85), the braking distance on wet and slippery surfaces is shortened to 1.5 meters. It monitors battery temperature and motor status in real-time, with a fault warning accuracy of 98% and an annual safety accident rate of less than 0.5%.
Keywords: intelligent safety protection, overload warning, fault warning
Flexible Control and Ergonomic Design for Easier Operation
With a minimum turning radius of only 1.1 meters and precise control via dual joysticks, it achieves a 100% success rate for U-turns in narrow channels (1.8 meters wide). The suspended operating handle can rotate 360°, with a gripping force of ≤4N, reducing hand fatigue by 60% after 4 hours of continuous operation, allowing female operators to work efficiently.
Keywords: flexible control, ergonomic design, labor-saving operation
High-strength Structure and Durable Components for Longer Service Life
The body is welded with Q460 high-strength steel, with a torsional strength of 800MPa, and remains undistorted after 100,000 load impact tests. The polyurethane wheels adopt an integrally formed process, with a wear rate 40% lower than ordinary wheels and a service life extended to over 3 years. The overall protection level is IP54, ensuring normal operation in dusty and splashing water environments.
Keywords: high-strength structure, durable components, IP54 protection
Low Energy Consumption, Energy Saving and Convenient Maintenance for Significant Cost Reduction
The motor energy conversion efficiency reaches 95%, saving 20% more energy than the industry average, with annual electricity costs reduced by approximately 1,200 yuan per unit. Core components (battery, motor) come with a 5-year warranty, and wearing parts adopt a quick-release structure, with replacement time ≤10 minutes. The annual maintenance cost is 30% lower than similar products.
Keywords: low energy consumption, energy saving, convenient maintenance, cost-controllable
Authoritative Certifications and Market Verification for Guaranteed Quality
Certified by ISO9001, CE, and FCC, each unit undergoes 800 lifting cycles and 100-kilometer endurance tests before leaving the factory, with a 100% pass rate. It has served over 3,000 enterprises, including Amazon warehouses and Gome Logistics, with a customer repurchase rate of 72% and a market reputation failure rate of only 0.3%.
Keywords: authoritative certifications, quality guarantee, enterprise customer recognition
◆◆ Technical Parameters
| Load Capacity | 1TON 2TON 2.5TON 3TON |
| Max Travel Speed | 4 - 6 km/h |
| Lift Height | 120 - 220 mm |
| Lift Speed | 10 - 20 mm/s |
| Battery Type | Lead-acid / Li-ion |
| Voltage/Capacity | 24V / 80 - 300 Ah |
| Operation Time | 4 - 8 H |
| Charging Time | 5 - 8 H (lead-acid) / 2 - 3 H (lithium-ion) |
| Gradeability | 3% - 10% |
| Min Turning Radius | 1,500 - 2,200 mm |
| Fork Dimensions | 1150*550mm/1220*685mm |
| Net Weight | 100 - 200KG |
◆◆ Product Uses
1. Long-Distance Transport in Large Warehouses
In distribution centers exceeding 5,000㎡, electric pallet trucks move pallets across zones (e.g., from docks to distant racking areas) at 4-6 km/h. With 8-hour continuous runtime, they triple the efficiency of manual models – ideal for high-flow sites like e-commerce fulfillment centers or logistics hubs.
2. High-Efficiency Cold Chain Operations
Freezer-spec models (-30°C rated) rapidly handle food/pharmaceutical pallets in cold storage. Equipped with frost-proof batteries + heated grips, they eliminate hydraulic failure risks of manual jacks in subzero temperatures, ensuring safe continuous operation.
3. Cross-Facility Mid-Distance Hauling
Connecting dispersed workshops (200m+ spans), electric trucks effortlessly tow full loads up 10% gradients (vs. 3% for manual). They synchronize seamlessly with automated production line cycles.
4. High-Frequency Loading Dock Relay
At ports/logistics parks, they partner with forklifts for rapid "dock-to-trailer" turnover: A single operator relocates cargo inside trucks in <3 minutes, reducing trailer idle time by 30%+.
5. Automation System Handoff Point
As AGV/conveyor interfaces, electric pallet trucks use positioning navigation for millimeter-precision docking. They transfer loads to automated systems (e.g., robotic sorters), eradicating manual handoff errors.
6. Multi-Floor Vertical Flow Optimization
In facilities with elevators, their rapid cabin entry/exit (vs. slow manual handling) combined with lift scheduling software accelerates cross-floor material flow by 50%.
◆◆ Product Operate Guide
1. Prepare：Insert forks fully into pallet base. Ensure load is centered and ≤ rated capacity. Check battery level & clear path.
2. Operate：Power ON → Release parking brake. Press handle controls:
3. Drive: Thumb lever forward/backward
4. Steer: Tilt handle left/right
5. Speed: Adjust with dial (start low!)
6. Lift/Lower：↑ Lift: Hold UP button until clearance reached
7. Lower: Press DOWN button smoothly
8. Park：Lower forks → Engage brake → Power OFF. Charge after shift (Use only approved charger).
◆◆ Product Video
◆◆ FAQ
Q: How long does the battery last per charge?
A: Typically 4-8 hours runtime. Actual duration depends on load weight, terrain, and usage frequency. Lithium batteries offer longer life (2,000+ cycles) vs. lead-acid (1,200 cycles). Always recharge when the battery meter drops below 20%.
Q: Can it handle slopes or uneven floors?
A: Yes, most models handle slopes ≤10% (≈5.7°). Use low-speed mode on inclines. Avoid uneven surfaces >3° to prevent instability. Never turn on slopes.
Q: What maintenance is required?
A:Monthly: Check tire wear & tighten bolts
Quarterly: Clean battery terminals
Annually: Hydraulic oil inspection
Avoid water jets when cleaning electronics.
Q: Is training needed to operate it?
A: Basic 2-hour training covers controls, load handling, slope safety, and emergency procedures. Operators must wear steel-toe shoes. Refresher courses recommended yearly.
Q: Why does the truck stop suddenly during use?
A: Safety auto-stop triggers when:
Controls are released
Overload detected (≥110% capacity)
Battery drops below 10%
