◆◆ Product Advantage
Zero-Emission Efficiency
Lithium-ion battery provides 8–10 hours of continuous operation
30% faster charging time compared to lead-acid batteries
EU Stage V emission compliance for green logistics
Intelligent Operation
LED display dashboard for real-time battery status
Anti-slip pedal and ergonomic joystick control
20% faster cycle times than manual pallet trucks
Enhanced Safety
Automatic overload protection (±10% capacity tolerance)
Emergency stop button and LED safety lighting
360° rotating headlights for low-visibility environments
Multi-Scenario Adaptability
-20°C to 60°C operating temperature range
IP54 waterproof rating for wet environments
Dock leveling system for seamless loading/unloading
◆◆ Technical Parameters
| Load Capacity | 1TON, 2TON, 2.5TON, 3TON |
| Max Travel Speed | 4 - 6 km/h |
| Lift Height | 120 - 220 mm |
| Lift Speed | 10 - 20 mm/s |
| Battery Type | Lead-acid / Li-ion |
| Voltage/Capacity | 24V / 80 - 300 Ah |
| Operation Time | 4 - 8 H |
| Charging Time | 5 - 8 H (Lead-acid) / 2-3 H (Li-ion) |
| Gradeability | 3% - 10% |
| Min Turning Radius | 1,500 - 2,200 mm |
| Fork Dimensions | 1150×550mm / 1220×685mm |
| Net Weight | 100-200KG |
◆◆ Product Uses
E-commerce Warehouses
High-density pallet stacking in automated warehouses
24/7 operation support for peak logistics seasons
Cold Chain Logistics
-20°C resistant models for frozen food warehouses
Anti-slip tires for icy warehouse floors
Retail Distribution Centers
Narrow-aisle maneuverability in hypermarkets
Pallet consolidation for cross-docking operations
Manufacturing Plants
JIT (Just-in-Time) material delivery to production lines
Collaborative operation with AGVs (Automated Guided Vehicles)
Urban Logistics
Zero-emission compliance for city-center warehouses
Quiet operation for nighttime delivery tasks
◆◆ Product Operate Guide
1. Prepare：Insert forks fully into pallet base. Ensure load is centered and ≤ rated capacity. Check battery level & clear path.
2. Operate：Power ON → Release parking brake. Press handle controls:
3. Drive: Thumb lever forward/backward
4. Steer: Tilt handle left/right
5. Speed: Adjust with dial (start low!)
6. Lift/Lower：↑ Lift: Hold UP button until clearance reached
↓ Lower: Press DOWN button smoothly
7. Park：Lower forks → Engage brake → Power OFF. Charge after shift (Use only approved charger).
◆◆ FAQ
Q1: How long does the battery last in extreme temperatures?
A: The lithium-ion battery retains 80% capacity at -20°C and 95% at 25°C. Extreme heat (>45°C) may reduce runtime by 10–15%.
Q2: Can this electric pallet truck operate outdoors?
A: Yes! Models with IP54 waterproof rating and all-terrain tires are suitable for light outdoor use (e.g., loading docks, uncovered
3.Q: Is training needed to operate it?
A: Basic 2-hour training covers controls, load handling, slope safety, and emergency procedures. Operators must wear steel-toe shoes. Refresher courses recommended yearly.
4.Q: Why does the truck stop suddenly during use?
A: Safety auto-stop triggers when:
Controls are released
Overload detected (≥110% capacity)
Battery drops below 10%
